Meridian Ellipse Wireless Speaker

• Meridian Ellipse is the third loudspeaker to emerge from our Extreme Engineering Programme, producing a natural, authentic and lifelike sound which is immersive and room-filling. Ellipse is designed for music enjoyment: with a bass response usually associated with much larger speakers, Ellipse has complete control over the sound it plays, so your music is projected into the room with clarity and authority.
• Ellipse is a complete Meridian system in a compact form factor. It is a distillation of everything we do, and it enables you to experience Meridian’s renowned sound quality in any room. Made in Britain using premium craftsmanship, its design is undeniably Meridian.
• Beautiful to look at, Ellipse is designed to subtly elevate any space. Its elliptical design signature echoes the design of other Meridian products. In combination with its harmonious curves, Ellipse boasts a luxuriously smooth, pebble-like surface in a deep, non-reflective black. Its soft and subtle finish is inviting to the touch, adding an element of style and sophistication to any modern living space. A perfect synthesis of function and form, within a timeless aesthetic.
• Ellipse offers superb flexibility with Bluetooth wireless technology and Wi-Fi streaming, while an Ethernet socket provides the option of a wired network connection.
• Supports AirPlay and works with Google Cast, as well as native streaming from Spotify Connect and TIDAL Connect. It is a Roon Ready device and can be used as a UPnP renderer.
• Twelve of Meridian’s unique DSP technologies make Ellipse capable of handling rooms of any size without compromise on sound quality.
• State-Of-The-Art-Craftmanship
• Each component has been meticulously specified for its acoustic benefits, aesthetic contribution, or both. Meridian Ellipse is rigorously engineered to deliver that Meridian signature sound performance in any room as well as being beautiful to look at and easy to use.
• Cutting-Edge Performance
• Ellipse takes the technological, engineering and manufacturing innovations in Meridian DSP8000 XE and DSP9 and distills them in a compact but extremely powerful package. An incredibly inert, perfectly sealed cabinet encloses powerful drive units and sophisticated signal-enhancing technologies. Unique control options, including Image Elevation technology and the innovative Bass and Space feature, allow the listener to tailor the sound to listening preferences, background noise levels, room size, and speaker placement.
• Effortless Simplicity
• Control at your fingertips. Playback functions fall easily to hand by virtue of the illuminated touch controls built into the top of the unit. Ellipse is easy to use and yet it supports a rich feature set which offers flexible set-up options and powerful user-settings.
• Engineered, designed and manufactured to deliver goosebumps, Ellipse epitomises our unique and unrivalled approach to audio playback.
• The Ellipse redefines what can be achieved from a product of its size.



• Streaming
  Bluetooth wireless technology, Wi-Fi streaming, Ethernet connectivity.
• AirPlay, Google Cast, native streaming from Spotify Connect and TIDAL Connect. Roon Ready, UPnP renderer.
• Audio inputs
  Internal streaming source
  1 x USB-C supporting sampling rates up to 192kHz @ 24-bit
  1 x mini-TOSLINK optical supporting sampling rates up to 96kHz @ 24 bit
  Stereo analogue with 88kHz/24bit A/D conversion (Optical and analogue share dual-purpose 3.5mm minijack socket)
• Control Options
  Illuminated touch controls located on top of unit
  Meridian Control app via Wi-Fi or Ethernet connection
  IR receiver eye (MSR2 remote control available separately)
  Automation interface via Wi-Fi or Ethernet connection
• Performance
  SPL: 100dB@1m (pink noise source)
• Frequency response in room within 3dB: 40Hz – 20kHz (volume setting 65)
• Amplification
  2 x 25W for full-range drivers
  1 x 30W for subwoofer driver
• Drive units
  2 x 90mm polypropylene wide-range drivers
  1 x 150mm x 100mm polypropylene long-throw “racetrack” subwoofer driver
• Crossover frequency = 180Hz
• Wi-fi operation
  Dual band - 2.4GHz and 5GHz compatible
• Dimensions / Weight
  WIDTH: 412mm [16.2in]
  DEPTH: 223mm [8.8in]
  HEIGHT: 171mm [6.7in]
  WEIGHT: 3.9kg [8.6lbs]
• Power
  100V – 240V AC, Max 70W



Click here to download documentation from the manufacturer
